| PART NUMBER |
DESCRIPTION |
SERIES |
MODEL |
AGGREGATE |
GROUP NO. |
GROUP NAME |
| AME017359 |
HYD Hose, 3/8 X 83" |
Backhoe |
MB63 BACKHOE (MAX 28XL) with THUMB ASSEMBLY SN# 1001 and LATER |
MB63 Backhoe |
MB63-4PTMOUHY-2-12 |
4-POINT MOUNT AND HYDRAULICS (PART 2) |
| AME017359 |
HYD Hose, 3/8 X 83" |
Backhoe |
Max 26Backhoe (Max 26Gear/Max 26 HST) |
Max 26Backhoe (Max 26Gear/Max 26 HST) |
MB63-4PTMOUHY-2-12 |
4-POINT MOUNT AND HYDRAULICS (PART 2) |
| AME017359 |
HYD Hose, 3/8 X 83" |
Backhoe |
25 Backhoe (eMax 22Gear/eMax 22HST/eMax 25HST) |
25 Backhoe |
MB63-4PTMOUHY-2-12 |
4-POINT MOUNT AND HYDRAULICS (PART 2) |
| AME017359 |
HYD Hose, 3/8 X 83" |
Backhoe |
EMAX 25B 6-1/4’ BACKHOE ( EMAX 22 and EMAX 25) SN # EMAX25B- From 2001 AND LATER |
EMAX25B (EMAX 22 and EMAX 25) |
EMAX25B (EMAX 22 AND EMAX 25)-FIG 12B |
4-POINT MOUNT AND HYDRAULICS PARTS BREAKDOWN |
| AME017359 |
HYD Hose, 3/8 X 83" |
Backhoe |
MAX 26B 6-1/2’ BACKHOE MAX 26XL and MAX 28XL)From SN# MAX26BXL-4001 AND LATER |
MAX 26XL AND MAX 28XL |
MAX 26XL & MAX 28XL-FIG 12 |
4-POINT MOUNT AND HYDRAULICS PARTS BREAKDOWN |
| AME017359 |
HYD Hose, 3/8 X 83" |
Backhoe |
MAX 26B 6-1/2’ BACKHOE MAX 26XL and MAX 28XL)From SN# MAX26BXL-4001 AND LATER |
MAX 26XL AND MAX 28XL |
MAX 26XL & MAX 28XL-FIG 12A |
4-POINT MOUNT AND HYDRAULICS PARTS BREAKDOWN |
| AME017359 |
HYD Hose, 3/8 X 83" |
Backhoe |
MAX 26B 6-1/2’ BACKHOE (MAX 26XL AND MAX 28XL) WITH SWIVEL SEAT ASSEMBLY SN# MAX26BXL-3001 AND LATER |
MAX26B (MAX 26XL AND MAX 28XL) |
MAX26B (MAX 26XL AND MAX 28XL) -FIG 17 |
4-POINT MOUNT AND HYDRAULICS PARTS BREAKDOWN |
| AME017359 |
HYD Hose, 3/8 X 83" |
Backhoe |
MAX 26B 6-1/2’ BACKHOE (MAX 26XL AND MAX 28XL) WITH SWIVEL SEAT ASSEMBLY SN# MAX26BXL-3001 AND LATER |
MAX26B (MAX 26XL AND MAX 28XL) |
MAX26B (MAX 26XL AND MAX 28XL) -FIG 19 |
SWIVEL SEAT PARTS BREAKDOWN |
| AME017359 |
HYD Hose, 3/8 X 83" |
Backhoe |
MAX 26B 6-1/2’ BACKHOE (MAX 26XL AND MAX 28XL) WITH SWIVEL SEAT ASSEMBLY SN# MAX26BXL-3001 AND LATER |
MAX26B (MAX 26XL AND MAX 28XL) |
MAX26B (MAX 26XL AND MAX 28XL) -FIG 18 |
4-POINT MOUNT AND HYDRAULICS PARTS BREAKDOWN |
| AME017359 |
HYD Hose, 3/8 X 83" |
Backhoe |
MAX 26B 6-1/4’ BACKHOE MAX 28XL and MAX 26B SERIES SN# 2001 and Later |
MAX 26B SERIES SN# 2001 AND LATER |
MAX 26B &SN# 2001-FIG 10 |
4-POINT MOUNT AND HYDRAULICS PARTS BREAKDOWN PART 1 |
| AME017359 |
HYD Hose, 3/8 X 83" |
Backhoe |
MAX 26B 6-1/4’ BACKHOE MAX 28XL and MAX 26B SERIES SN# 2001 and Later |
MAX 26B SERIES SN# 2001 AND LATER |
MAX 26B &SN# 2001-FIG 10A |
4-POINT MOUNT AND HYDRAULICS PARTS BREAKDOWN PART 2 |
| AME017359 |
HYD Hose, 3/8 X 83" |
Backhoe |
EMAX 25B 6-1/4’ BACKHOE ( EMAX 22 and EMAX 25) SN # EMAX25B- From 1001 AND LATER |
EMAX 22 and EMAX 25 |
EMAX 25B 6-1/4’ BACKHOE _FIG 10B |
4-POINT MOUNT AND HYDRAULICS PARTS BREAKDOWN PART 3 |
| AME017359 |
HYD Hose, 3/8 X 83" |
Backhoe |
MAX 26B 6-1/4’ BACKHOE MAX 28XL and MAX 26B SERIES SN# 2001 and Later |
MAX 26B SERIES SN# 2001 AND LATER |
MAX 26B &SN# 2001-FIG 12 |
SWIVEL SEAT PARTS BREAKDOWN |
