Mahindra Loader Float Detent Spool Repair Kit KMW05806025 – Prince Valves ML114, ML170, ML214, ML230, ML245, ML260, ML264, ML265, ML266, ML270, ML275, ML276

Was: $495.00

Now: $421.99

No reviews yet Write a Review

Mahindra loader float detent spool repair kit KMW05806025 services the float-position boom spool in Prince loader valves on KMW ML114, ML170, ML214, ML230, ML245, ML260, ML264, ML265, ML266, ML270, ML275, and ML276 loaders for Mahindra 3505/4005/4505/5005, 4510, 4530, 4500/5500/6000/6500 2WD and 4WD, 6520/7520, 5530/6030, and 7010 tractors, replacing detent balls, springs, and seals so the loader boom locks properly into float.

SKU:: KMW05806025

Product Description

PART NUMBER	DESCRIPTION	SERIES	MODEL	AGGREGATE	GROUP NO.	GROUP NAME
KMW05806025	FLOAT Detent Spool Repair Kit	Loader	KMW-ML114 Loader (4510 4WD Cab)	ML114 Loader (KMW)	04010303	PRINCE LOADER VALVE LOADER S/N 042115614-CURRENT
KMW05806025	FLOAT Detent Spool Repair Kit	Loader	KMW-ML170 Loader (7010 Cab)	ML170 Loader (KMW)	04010335	PRINCE LOADER VALVE LOADER S/N 044619928-CURRENT
KMW05806025	FLOAT Detent Spool Repair Kit	Loader	KMW-ML214 Loader-3505/4005/4505/5005	ML214 Loader (KMW)	04010391	HYDRAULIC VALVE ASSEMBLY LOADER S/N 040813734-CURRENT
KMW05806025	FLOAT Detent Spool Repair Kit	Loader	KMW-ML230 Loader-3505/4005/4505/5005	ML230 Loader (KMW)	04010391	HYDRAULIC VALVE ASSEMBLY LOADER S/N 040813734-CURRENT
KMW05806025	FLOAT Detent Spool Repair Kit	Loader	ML245 Loader (4530 4WD) (From Serial # 101651250)	ML245 Loader (KMW)	04010419	LOADER VALVE (PRINCE) S/N 043718346 - 101651249
KMW05806025	FLOAT Detent Spool Repair Kit	Loader	KMW-ML260 Loader (4500/5500/6000 2WD)	ML260 Loader	04010489	HYDRAULIC VALVE ASSEMBLY LOADER S/N 040813694-CURRENT
KMW05806025	FLOAT Detent Spool Repair Kit	Loader	KMW-ML264 Loader (6000 4WD)	ML264 Loader (KMW)	04010537	PRINCE LOADER VALVE
KMW05806025	FLOAT Detent Spool Repair Kit	Loader	KMW-ML265 Loader (5500/6000/6500 4WD)	ML265 Loader (KMW)	04010577	PRINCE LOADER VALVE LOADER S/N 040313014-CURRENT
KMW05806025	FLOAT Detent Spool Repair Kit	Loader	KMW-ML266 Loader (5530/6030)	ML266 Loader (KMW)	6P03190027	PRINCE LOADER VALVE
KMW05806025	FLOAT Detent Spool Repair Kit	Loader	KMW-ML270 Loader (6520/7520)	ML270 Loader (KMW)	04010615	PRINCE LOADER VALVE LOADER S/N 044519681-CURRENT
KMW05806025	FLOAT Detent Spool Repair Kit	Loader	KMW-ML275 Loader (6520/7520 4WD)	ML275 Loader (KMW)	04010655	PRINCE LOADER VALVE
KMW05806025	FLOAT Detent Spool Repair Kit	Loader	KMW-ML276 Loader (6520/7520)	ML276 Loader (KMW)	ML276L - PLV-1-08	PRINCE LOADER VALVE
KMW05806025	FLOAT Detent Spool Repair Kit	Loader	ML245 Loader (Serial No. From 043718346 - 101651225)	ML245 Loader (KMW)	ML245 LOADER (KMW)_FIG 18	PRINCE LOADER VALVE (SERIAL NO. 054728792 - CURRENT)
