Mahindra Pin Rod End 000039374D For Clutch Hand Brake 4WD Engagement Steering & Differential Linkages On Multiple C 00 20 25 30 35 3500 4500 5500 6000 6500 Series Tractors

Product Description
Specifications

PART NUMBER	DESCRIPTION	SERIES	MODEL	AGGREGATE	GROUP NO.	GROUP NAME	REF NO.
000039374D	PIN Rod End	C Series	C27	Clutch	01050107	CLUTCH PEDAL & CONNECTION	7
000039374D	PIN Rod End	25 Series	3325 2WD T2	Throttle Linkages	3325-FTL-11	FOOT THROTTLE LINKAGES	5
000039374D	PIN Rod End	25 Series	5525 2WD T2	Clutch	6P03160079	CLUTCH HOUSING AND CONNECTIONS (PART 2)	41
000039374D	PIN Rod End	25 Series	6025 2WD T2	Clutch	6P03160079	CLUTCH HOUSING AND CONNECTIONS (PART 2)	41
000039374D	PIN Rod End	C Series	C35	Clutch	01050105	CLUTCH PEDAL & CONNECTION	7
000039374D	PIN Rod End	35 Series	3535 Gear	Steering & Linkages	35G-WC-1-08	WHEEL AND COLUMN	16
000039374D	PIN Rod End	35 Series	4035 Gear	Steering & Linkages	35G-WC-1-08	WHEEL AND COLUMN	16
000039374D	PIN Rod End	00 Series	4500 4WD	Brakes	01040301	HAND BRAKE LINKAGES	7
000039374D	PIN Rod End	00 Series	5500 4WD	Brakes	01040301	HAND BRAKE LINKAGES	7
000039374D	PIN Rod End	00 Series	6000 4WD	Brakes	01040301	HAND BRAKE LINKAGES	7
000039374D	PIN Rod End	00 Series	4500 4WD	I.P.T.O. & Transmission	01040285	2 WD TO 4 WD SHIFTING ARRANGEMENT	4
000039374D	PIN Rod End	00 Series	5500 4WD	I.P.T.O. & Transmission	01040285	2 WD TO 4 WD SHIFTING ARRANGEMENT	4
000039374D	PIN Rod End	00 Series	6000 4WD	I.P.T.O. & Transmission	01040285	2 WD TO 4 WD SHIFTING ARRANGEMENT	4
000039374D	PIN Rod End	00 Series	6500 4WD	I.P.T.O. & Transmission	01040285	2 WD TO 4 WD SHIFTING ARRANGEMENT	4
000039374D	PIN Rod End	00 Series	4500 2WD	Brakes	01260277	HAND BRAKE LINKAGES	7
000039374D	PIN Rod End	00 Series	5500 2WD	Brakes	01260277	HAND BRAKE LINKAGES	7
000039374D	PIN Rod End	00 Series	6000 2WD	Brakes	01260277	HAND BRAKE LINKAGES	7
000039374D	PIN Rod End	00 Series	6500 2WD	Brakes	01260277	HAND BRAKE LINKAGES	7
000039374D	PIN Rod End	00 Series	4500 2WD	Clutch	01260211	CLUTCH HOUSING AND CONNECTIONS (PART 2)	42
000039374D	PIN Rod End	30 Series	4530 4WD T2	Brakes	01250117	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	30 Series	4530 4WD T2	Clutch	4530-4WD-CHC1-11	CLUTCH HOUSING AND CONNECTIONS 1	29
000039374D	PIN Rod End	30 Series	4530 4WD T2	Differential & Rear Axle	01250109	DIFFERENTIAL LOCK	20
000039374D	PIN Rod End	30 Series	4530 4WD T2	Transmission	01250089	4WD ENGAGEMENT LINKAGES	4
000039374D	PIN Rod End	30 Series	4530 4WD T2	Transmission	01250095	DIRECTION CONTROL ARRANGEMENT	15
000039374D	PIN Rod End	30 Series	4530 4WD T2	Transmission	01250101	IPTO MECHANISM	23
000039374D	PIN Rod End	35 Series	4535 Gear	Steering & Linkages	4535-W&C-10	WHEEL AND COLUMN	16
000039374D	PIN Rod End	30 Series	4530 4WD-T4	Clutch	4530-4WD-T4-CHC1-11	CLUTCH HOUSING AND CONNECTIONS 1	29
000039374D	PIN Rod End	30 Series	4530 4WD-T4	IPTO & Transmission	45304-T4-4WDEL-10	4WD ENGAGEMENT LINKAGES	4
000039374D	PIN Rod End	30 Series	4530 4WD-T4	IPTO & Transmission	45304-T4-DCA-10	DIRECTION CONTROL ARRANGEMENT	15
000039374D	PIN Rod End	30 Series	4530 4WD-T4	IPTO & Transmission	45304-T4-IPTOM1-10	IPTO MECHANISM (PART 1)	23
000039374D	PIN Rod End	30 Series	4530 4WD-T4	Differential & Rear Axle	45304-T4-DIFFL-10	DIFFERENTIAL LOCK	20
000039374D	PIN Rod End	30 Series	4530 4WD-T4	Brakes	45304-T4-HBA-10	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	35 Series	4035 HST	Steering & Linkages	4035H-W&C-10	WHEEL AND COLUMN	16
000039374D	PIN Rod End	35 Series	4035 PST	Steering And Linkages	4035P-W&C-10	WHEEL AND COLUMN	16
000039374D	PIN Rod End	25 Series	4025 4WD T4	C.R.P.T.O. & Transmission	'01_4025_0001_0089-M'	4WD ENGAGEMENT LINKAGES	4
000039374D	PIN Rod End	3500 Series	3540 HST T4	Steering And Linkages	3540H-WC-13	WHEEL AND COLUMN	16
000039374D	PIN Rod End	4500 Series	4540 4WD-T4	C.R.P.T.O. & Transmission	4540-4EL-13	4WD ENGAGEMENT LINKAGES	4
000039374D	PIN Rod End	5500 Series	5545 4WD-T4 Synchro	Clutch	5545S-CHC1-13	CLUTCH HOUSING AND CONNECTIONS (PART 1)	29
000039374D	PIN Rod End	5500 Series	5545 4WD-T4 Synchro	IPTO & Transmission	5545S-4EL-13	4WD ENGAGEMENT LINKAGES	4
000039374D	PIN Rod End	5500 Series	5545 4WD-T4 Synchro	IPTO & Transmission	55452-DCA-13	DIRECTION CONTROL ARRANGEMENT	15
000039374D	PIN Rod End	5500 Series	5545 4WD-T4 Synchro	IPTO & Transmission	5545S-IM1-13	IPTO MECHANISM (PART 1)	23
000039374D	PIN Rod End	5500 Series	5545 4WD-T4 Synchro	Differential & Rear Axle	5545S-DL-13	DIFFERENTIAL LOCK	20
000039374D	PIN Rod End	5500 Series	5545 4WD-T4 Synchro	Brakes	5545S-HBA-13	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	00 Series	5500 2WD	Clutch	01260209	CLUTCH HOUSING AND CONNECTIONS (PART 2)	42
000039374D	PIN Rod End	00 Series	6000 2WD	Clutch	01260209	CLUTCH HOUSING AND CONNECTIONS (PART 2)	42
000039374D	PIN Rod End	00 Series	6500 2WD	Clutch	01260209	CLUTCH HOUSING AND CONNECTIONS (PART 2)	42
000039374D	PIN Rod End	30 Series	5530 4WD T2	Brakes	6P03180127	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	30 Series	6030 4WD T2	Brakes	6P03180127	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	30 Series	5530 4WD T2	Clutch	5530-4WD-CHC2-11	CLUTCH HOUSING AND CONNECTIONS 2	29
000039374D	PIN Rod End	30 Series	5530 4WD T2	IPTO & Transmission	6P03180097	4WD ENGAGEMENT LINKAGES	4
000039374D	PIN Rod End	30 Series	6030 4WD T2	IPTO & Transmission	6P03180097	4WD ENGAGEMENT LINKAGES	4
000039374D	PIN Rod End	30 Series	5530 4WD T2	IPTO & Transmission	6P03180103	DIRECTION CONTROL ARRANGEMENT	15
000039374D	PIN Rod End	30 Series	6030 4WD T2	IPTO & Transmission	6P03180103	DIRECTION CONTROL ARRANGEMENT	15
000039374D	PIN Rod End	30 Series	5530 4WD T2	IPTO & Transmission	6P03180109	IPTO MECHANISM	23
000039374D	PIN Rod End	30 Series	6030 4WD T2	IPTO & Transmission	6P03180109	IPTO MECHANISM	23
000039374D	PIN Rod End	30 Series	6030 4WD T2	Clutch	6030-4WD-CHC2-11	CLUTCH HOUSING AND CONNECTIONS 2	29
000039374D	PIN Rod End	30 Series	5530 2WD-T3	Clutch	5530-2WD-T3-CHC2-11	CLUTCH HOUSING AND CONNECTIONS 2	29
000039374D	PIN Rod End	30 Series	5530 2WD-T3	IPTO, SLPTO & Transmisison	5530IPTOM1-1-08	IPTO MECHANISM 1	23
000039374D	PIN Rod End	30 Series	5530 2WD-T3	IPTO, SLPTO & Transmisison	5530DCA-1-12	DIRECTION CONTROL ARRANGEMENT	15
000039374D	PIN Rod End	30 Series	5530 2WD-T3	Brakes	5530HBA-1-08	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	30 Series	5530 4WD-T3	Clutch	5530-4WD-T3-CHC2-11	CLUTCH HOUSING AND CONNECTIONS 2	29
000039374D	PIN Rod End	30 Series	5530 4WD-T3	IPTO, SLPTO & Transmission	55304WD4EL-1-08	4WD ENGAGEMENT LINKAGES	4
000039374D	PIN Rod End	30 Series	5530 4WD-T3	IPTO, SLPTO & Transmission	55304WDDCA-1-08	DIRECTION CONTROL ARRANGEMENT	15
000039374D	PIN Rod End	30 Series	5530 4WD-T3	IPTO, SLPTO & Transmission	55304WDIM1-1-08	IPTO MECHANISM 1	23
000039374D	PIN Rod End	30 Series	5530 4WD-T3	Differential & Rear Axle	55304WD-DRA-DL-1-08	DIFFERENTIAL LOCK	23
000039374D	PIN Rod End	30 Series	5530 4WD-T3	Brakes	55304WDHBA-1-08	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	25 Series	5525 2WD-T3	Clutch	55252WDCHC2-1-08	CLUTCH HOUSING AND CONNECTIONS 2	41
000039374D	PIN Rod End	35 Series	5035 Gear	Steering & Linkages	5035-W&C-1-09	WHEEL AND COLUMN	16
000039374D	PIN Rod End	35 Series	5035 HST	Steering & Linkages	5035H-W&C-10	WHEEL AND COLUMN	16
000039374D	PIN Rod End	30 Series	5530 2WD-T3 (Synchro Shuttle)	Clutch	5530-2WD-T3-SS-CHC2-11	CLUTCH HOUSING AND CONNECTIONS 2	29
000039374D	PIN Rod End	30 Series	5530 2WD-T3 (Synchro Shuttle)	IPTO, SLPTO & Transmission	55302-SS-DCA-F-10	DIRECTION CONTROL ARRANGEMENT - FROM SMSTS 1001	15
000039374D	PIN Rod End	30 Series	5530 2WD-T3 (Synchro Shuttle)	IPTO, SLPTO & Transmission	55302-SS-IPTOM1-U-10	IPTO MECHANISM (DISCONTINUED) (PART 1) - UPTO SMST 1180	23
000039374D	PIN Rod End	30 Series	5530 2WD-T3 (Synchro Shuttle)	Brakes	55302-SS-HBA-10	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	35 Series	5035 PST	Steering And Linkages	5035P-W&C-10	WHEEL AND COLUMN	16
000039374D	PIN Rod End	5500 Series	5555 4WD-T4 Synchro	Clutch	55554T4-CHC2-13	CLUTCH HOUSING AND CONNECTIONS - PART 2	29
000039374D	PIN Rod End	5500 Series	5555 4WD-T4 Synchro	IPTO Gears & Shafts	55554T4-4WDEL-13	4WD ENGAGEMENT LINKAGES	4
000039374D	PIN Rod End	5500 Series	5555 4WD-T4 Synchro	IPTO Gears & Shafts	55554T4-DCA-13	DIRECTION CONTROL ARRANGEMENT	15
000039374D	PIN Rod End	5500 Series	5555 2WD-T4 Synchro	Brakes	55552T4-HBA-13	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	3500 Series	3550 HST T4	Steering & Linkages	3550H-WC-13	WHEEL AND COLUMN	16
000039374D	PIN Rod End	00 Series	6500 4WD	Brakes	01040303	HAND BRAKE LINKAGES	7
000039374D	PIN Rod End	30 Series	6530 4WD T2	Brakes	05_13_0121	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	30 Series	6530 4WD T2	Clutch	6530-4WD-CHC2-11	CLUTCH HOUSING AND CONNECTIONS 2	29
000039374D	PIN Rod End	30 Series	6530 4WD T2	SLPTO & Transmission	05_13_0091	4WD ENGAGEMENT LINKAGES	4
000039374D	PIN Rod End	30 Series	6530 4WD T2	SLPTO & Transmission	05_13_0097	DIRECTION CONTROL ARRANGEMENT	15
000039374D	PIN Rod End	30 Series	6030 2WD-T3	Clutch	6030-2WD-T3-CHC2-11	CLUTCH HOUSING AND CONNECTIONS 2	29
000039374D	PIN Rod End	30 Series	6030 2WD-T3	IPTO, SLPTO & Transmission	6030IPTOM1-1-08	IPTO MECHANISM 1	23
000039374D	PIN Rod End	30 Series	6030 2WD-T3	Brakes	6030HBA-1-08	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	30 Series	6530 2WD-T3	Clutch	6530-2WD-T3-CHC2-11	CLUTCH HOUSING AND CONNECTIONS 2	29
000039374D	PIN Rod End	30 Series	6530 2WD-T3	Differential & Rear Axle	6530DL-1-08	DIFFERENTIAL LOCK	23
000039374D	PIN Rod End	30 Series	6530 4WD-T3	Differential & Rear Axle	6530DL-1-08	DIFFERENTIAL LOCK	23
000039374D	PIN Rod End	30 Series	6530 2WD-T3	Brakes	65304WDT3-HBA-12	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	30 Series	6530 4WD-T3	Brakes	65304WDT3-HBA-12	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	30 Series	6530 2WD-T3	IPTO, SLPTO & Transmission	65302WDT3-DCA-12	DIRECTION CONTROL ARRANGEMENT	15
000039374D	PIN Rod End	30 Series	6030 4WD-T3	Clutch	6030-4WD-T3-CHC2-11	CLUTCH HOUSING AND CONNECTIONS 2	29
000039374D	PIN Rod End	30 Series	6030 4WD-T3	IPTO, SLPTO & Transmission	60304WDEL-1-08	4WD ENGAGEMENT LINKAGES	4
000039374D	PIN Rod End	30 Series	6030 4WD-T3	IPTO, SLPTO & Transmission	60304WDDCA-1-08	DIRECTION CONTROL ARRANGEMENT	15
000039374D	PIN Rod End	30 Series	6030 4WD-T3	IPTO, SLPTO & Transmission	60304WDIM1-1-08	IPTO MECHANISM 1	23
000039374D	PIN Rod End	30 Series	6030 4WD-T3	Brakes	60304WDHBA-1-08	HAND BRAKE ASSEMBLY	9
000039374D	PIN Rod End	25 Series	6525 2WD-T3	Clutch	65252WDCHC2-1-08	CLUTCH HOUSING AND CONNECTIONS 2	41
000039374D	PIN Rod End	30 Series	6530 4WD-T3	IPTO, SLPTO & Transmission	65304WDEL-1-08	4WD ENGAGEMENT LINKAGES	4
